| ⌀ d1* (mm) | b1 (mm) | b2 (mm) | Wheel load max. in kg |
|---|---|---|---|
| 160 | 75 | 100 | 8.800 |
| 200 | 75 | 100 | 11.200 |
| 250 | 80 | 110 | 16.000 |
| 315 | 90 | 125 | 22.000 |
| 400 | 60 - 90 | 125 | 28.000 |
| 85 - 105 | 140 | ||
| 500 | 60 - 100 | 140 | 40.000 |
| 95 - 130 | 170 | ||
| 630 | 75 - 130 | 170 | 60.000 |
| 100 - 160 | 210 |
* ⌀ d1 refers to wheel diameter
Wheel set RAE series 160, 200, 250 and 315 for corner bearing installation complete or for box girder installation in individual parts
Wheel set RNE series 160, 200, 250 and 315 for corner bearing installation complete or for box girder installation in individual parts
Wheel set RAE series 400, 500 and 630 for corner bearing installation complete or for box girders in individual parts
Wheel set RNE series 400, 500 and 630 for corner bearing installation complete or for box girders in individual parts
–30 °C to +90 °C (+200 °C Max.)
Up to 60 tons
High availability
Easy installation
Flexible drive selection
Karl Georg‘s decades of experience offer a wide range of specific product solutions for special applications, conditions and interfaces. Thanks to flexible manufacturing concepts and a high level of vertical integration, we are able to offer special solutions from a quantity of 1. Our experts will be happy to help you.
